Description

This is a stuffing kit for the F5 V3 PCBs.

It does not include the JFETs for Q1 and Q2 or the F5 PCB.

See the PCB page for more information including the F5v3 Build Guide.

Good for 2 channels.

F5 V3 BOM

Part Value Qty. In this kit? Notes
R1 4.75k 2 Yes
R2
47.5k 2 Yes
R3, R4 10R 4 Yes
R5, 6, 21, 22 2.21k 8 Yes A few extra 2.21K resistors are included for the R5 R6 positions in case extra series resistance in needed to get the bias up to proper levels. Most builders will not need them, but they are nice to have on hand.
R7, R8 .47R 3W 4 Yes
R9, 10, 11,12 100R 3W 8 Yes
R13, 14, 17, 18 100R 8 Yes
R15, R16 1k 4 Yes
R19, R20 10k 4 Yes
P1, P2 5k 4 Yes
P3 200R 2 Yes
TH1, TH2 4.7k 4 Yes
Q1 2SK170 2 No Source Q1 and Q2 Separately as 2 matched NP pairs*
Q2 2SJ74 2 No Source Q1 and Q2 Separately as 2 matched NP pairs*
Q3 IRFP9240 2 Yes
Q4 IRFP240 2 Yes
Q5 ZTX550 2 Yes
Q6 ZTX450 2 Yes
