DIY Biamp 6-24 Crossover
The DIY BIAMP 6-24 kit is a stereo analog active biamp crossover circuit designed for high flexibility. Featuring 12 discrete Jfet buffer circuits operated without negative feedback, it offers 16 continuously adjustable filter elements in two low-pass and two high-pass filters with slopes of 6, 12, 18, or 24 dB per octave and various “Q” characteristics. It has flexibility not generally offered by crossover products have “textbook” characteristics, allowing more detailed tailoring of filters around the actual character of different loudspeaker drivers.
- 24 JFETs (selected for Idss and matched for optimal performance)
- 24 biasing resistors (matched to the JFETs for optimal performance)
Photography by Thuss and Farrell.
A great product - just what I was hoping to find. No complaints regarding the board that was supplied. Very good quality. I would like to weigh in on the discussion about supplying this product for Surface Mount Components. If the board were designed for surface mount, I would guess that there are many like myself that would not be inclined to attempt the build. Please continue with through hole products.
The 6-24XO gives you the chance to build an excellent sounding 2-way - active -crossover (stereo) on one pcb.
The kit includes well matched J113 - JFets for the buffers. No Opamps involved.
The pcb is of very good quality. Delivery was very fast (as well the german customs).
Great kit - your chance to go 'active'.....
This is a super versatile active crossover! Slopes from 6-24dB/oct.! Also a bandpass possible.
I used it to actively cross at around 2.5kHz for a 2-way speaker. Sounds superb!
PCB of great quality. JFets very good matched.
Delivery very fast from USA to Germany (although there is the Pandemia).Good job DIYaudiostore!
Thanks Nelson Pass! This is a great 'sound-machine'
I go listen... Dirk
Good idea, top quality.
diyaudio store ist best.
Cons, eu warehouse is missing. Vat + shipping is same price as diy-kit
With a lifelong interest in high quality stereo audio, and as a diy loudspeaker and amplifier builder, the diy audio store is GREAT for me. I don’t have an education in electronics, my knowledge of it is basic. So, kits are great for me! Especially if they are designed by audio heroes like Nelson Pass, the pcb’s and chosen components are of high quality and the building process is well documented. I was looking for a universal active crossover for a long time, so I was very happy when I found this kit in the DIY Audio Store! I haven’t build it yet, but I am sure it will be a great sounding cross-over. Keep up the good work!
This is one of those projects I thought I would never need. Since buying a pair of Full Range drivers, I needed a crossover to pair them with my subwoofer. I'm building a BA2018 preamp with the 6-24 Crossover integrated in the case, the PCB is small enough to fit in a small enclosure with BA2018 PCB. Best part of all, when I had a question on building the Crossover, it was Nelson himself who answered it.
Received my circuit board and transistors rapidly. Quality packaging. This is just a beautiful PCB, superbly laid out, component values clearly indicated, and it's plenty thick and stout. Very happy with this purchase. Can't wait to build. Just need some time!
