Amp Camp Amp PCB

Part of the Amp Camp Amp project
Choose ConfigurationCurrently Selected: PCBs Only
Both chassis styles (silver and black), the PSU and the parts kit. Please note only 1 chassis is included in the complete kit, you must choose which style you prefer.
complete-kit
Complete Kit
$ 359.00 USD
parts-pcb-only
Parts & PCB Only
$ 135.00 USD
pcbs-only
PCBs Only
$ 10.00 USD
$ 10.00
OptionTin traces
Two of the latest Amp Camp Amp PCBs, good for 2 channels of amplification.

These are the current revision of the PCB, which says "V1.6" on the PCB. The ACA V1.8 kit uses these PCBs, as there was no change to the PCB from 1.6 to 1.8 (other things in the kit did change).

These are available with either:
  • Tinned copper traces
  • Gold plated copper traces
The official ACA kits have used either over the years, and experts would tell you the trace material makes no difference at all to the sound. Choose what feels right to you.

Dimensions 88mm x 57mm
Mounting holes UMS Heatsink Compatible
Number of boards included 2
Layers 2
Board Revision 1.6
Board Color Green
Tracks 35um copper

Amp Camp Amp Project

  • Power Amplifier
  • Designed by Nelson Pass
  • Beginner Difficulty
  • Comprehensive Build Guide
  • Complete Kit Available
Contributors
  • THUSS + FARRELL (Photography)
  • Jim Tiemann (Build Guide)

Visit the Amp Camp Amp project page for more information about this project.


[{"variant_id":"16373247213602" , "metafield_value":""},{"variant_id":"5938996356" , "metafield_value":""}]

Amp Camp Amp PCB

$ 10.00 USD

Note - Photos include parts available at the time of publishing. Individual components are subject to change based on availability.

Customer Reviews

Based on 26 reviews
96%
(25)
4%
(1)
0%
(0)
0%
(0)
0%
(0)
W
William P.
DIYer

Good quality boards. However, I perchased the boards becasue of the circuit design.
THANK YOU NELSON PASS. Very unselfish as he always has been.

G
Gary W.
Very warm

In more ways than one , this amp is fantastic. Assembly was well documented, well supported by the online community of builders. Worked first time.
Musicality of this amp is wonderful. I'm building a second amp for bridged operation.

J
JAREK
I recommend

I bought Amp Camp PCBs, they are of very good quality. I have not yet completed the elements, so I will not describe the opinion on the sound of the amplifier yet. I rate the project handling as perfect. Jarek

B
Bruce A.
Amp Camp 1.6 PCB's

Excellent Quality!
I ordered 2 sets with the Tin Traces. Very Happy!
No Problems at all with the build.
The ACA Units work perfectly and with the
diyaudio cases look very professional!

M
Marcin G.

First of all excellent quality and customer service, and fast delivery... Thank's

D
Dennis F.
ACA version 1.6 boards

The circuit boards are of excellent quality, and affordable!!! I bought them to use as my finished amp configuration after much experimenting with the originals in making circuit changes to tune the amp to my system.
